Marin
Marin: Nicasio - 2024

Marin

Marin: Nicasio - 2024

$899.00
(No reviews yet) Write a Review
Condition:
New
Adding to cart… The item has been added

Description

Marin: Nicasio - 2024

Marin's Nicasio is a modern style road bike from Marin that features traditional steel construction with the soul of a classic bike, the geometry and 700C x 30mm (up to 40mm) tires to let riders handle any surface. Available at Bike Attack Santa Monica, Playa Vista, Culver City, Los Angeles.



ADVENTURE ROAD AND OFF-ROAD RIDING

LONG DISTANCE COMMUTING

ENDURANCE AND ALL-WEATHER PAVEMENT

The most affordable model in the family, the base-spec Marin Nicasio is built around a smooth-riding and stylish Series 1 double-butted CrMo frame and fork and zippy 700C wheels, with room for up to 35mm tires. We’ve specced a 2x8-speed Shimano Claris drivetrain, Vee Tire rubber, powerful mechanical discs and plenty of Marin components.



SPECIFICATIONS

  • FRAME

    Series 1 Double Butted CrMo Beyond Road, 700C Wheels, Beyond Road Geometry, Fender and Rack Mounts, Disc Mount

  • FORK

    CrMo, Fender and Rack Eyelets, IS Disc Mount

  • RIMS

    Marin Aluminum Double Wall, 19mm Inner, Disc Specific

  • HUB, REAR

    Forged Aluminum Alloy, Disc, 32H

  • HUB, FRONT

    Forged Aluminum Alloy, Disc, 32H

  • SPOKE, NIPPLES

    14g Black Stainless Steel

  • TIRES

    Vee Tire Co, Road Chief, 700Cx30, Wire Bead

  • DERAILLEUR, REAR

    Shimano Claris 8-Speed

  • DERAILLEUR, FRONT

    Shimano Claris

  • SHIFT LEVER

    Shimano Claris 2x8-Speed

  • CRANKSET

    FSA Tempo Compact, 50/34T

  • BOTTOM BRACKET

    Sealed Cartridge Bearings, Square Taper

  • CHAIN

    KMC Z8

  • CASSETTE

    SunRace 8-Speed, 11-32T

  • BRAKE, FRONT

    Tektro MDC400, Road Mechanical, 160mm Rotor

  • BRAKE, REAR

    Tektro MDC400, Road Mechanical, 160mm Rotor

  • BRAKE LEVERS

    Shimano w/ Integrated Shifters

  • HANDLEBAR

    Marin Butted Alloy, Compact 12º Flared Drop

  • STEM

    Marin 3D Forged Alloy

  • GRIPS

    Marin Comfort Tape

  • HEADSET

    FSA No.8D, Sealed Cartridge Bearings

  • SEATPOST

    Marin Alloy, 27.2mm

  • SADDLE

    Marin Beyond Road Concept

  • PEDALS

    Marin Oso OEM Nylon Platform

Specifications, pricing, and availability are subject to change without notice.



GEOMETRY

  47505254565860
STACK 534.57 541.26 555.4 574.52 590.64 609.72 619.25
REACH 349.75 359.8 360.48 378.42 384.42 398.59 404.75
HEADTUBE ANGLE 70° 70.5° 70.5° 72° 72.5° 72.5° 72.5°
HEADTUBE LENGTH 125 130 145 155 170 190 200
SEATTUBE ANGLE (ACTUAL) 74.5° 74° 73.5° 73.5° 73° 73° 72.5°
SEATTUBE LENGTH 440 470 490 510 530 550 570
TOPTUBE (EFFECTIVE) 498 515 525 545 565 585 600
BOTTOM BRACKET HEIGHT 269 269 269 269 269 269 269
BOTTOM BRACKET DROP 72 72 72 72 72 72 72
CHAINSTAY 420 420 420 420 420 420 420
WHEELBASE 992.55 1000.22 993.92 999.2 1008.92 1029.1 1038.26
STANDOVER HEIGHT 697.12 721.09 741.53 758.79 777.05 796.2 812.46
FORK OFFSET 57 57 57 45 45 45 45
SEATPOST DIAMETER 27.2 27.2 27.2 27.2 27.2 27.2 27.2
HANDLEBAR WIDTH 400 400 400 420 420 440 440
STEM LENGTH 75 75 75 90 90 90 90
CRANK LENGTH 170 170 170 175 175 175 175

All lengths in millimeters
