Description
Marin: Alcatraz 2025
Marin's Alcatraz is a rad mountain bike that allows the rider to follow in Matt Jones’ footsteps to build and personalize the best dirt jump bike possible. At home boosting your local 6 pack, ripping up the pump track, or hitting the local skate park the Alcatraz has what you need to take care of business. Now available at Bike Attack Playa Vista.
DIRT JUMPS
SLOPESTYLE
PUMP TRACK
SKATE PARK
The Series 3 aluminum frame is built for the hard knocks and is stiff enough for lightning-fast acceleration and tough enough for the heavy hits. Short stays keep manuals easy and ambidextrous cable routing means you can run your brake on the left or right of the bars. There’s a 100mm Manitou Expert coil fork, front and rear Tektro hydraulic disc brakes, Vee Tire rubber and plenty of bombproof Marin components. Best of all, it’s available in two frame sizes, regular and long.
SPECIFICATIONS
-
FRAME
Series 3 6061 Aluminum, 26” Wheels, 135x10mm Horizontal Single Speed Dropouts, 73mm Threaded BB, ISCG 05 Tabs
-
FRONT SUSPENSION
Manutou Circus Expert, 26", 100mm Travel, Coil Spring, Taper Steerer Tube, 20x110mm Thru Axle
-
REAR SUSPENSION
-
-
RIMS
Marin Custom Extrusion, 27mm Inner, Pinned Joint
-
HUB, REAR
Forged Alloy, 135x10mm, Bolt-On, Quad Sealed Bearings, Disc, 32H
-
HUB, FRONT
Forged Alloy, 110x20mm, Disc, 32H
-
SPOKE, NIPPLES
14g Black Stainless Steel
-
TIRES
Vee Tire Co. XCV 26x2.25”, LSG Compound, Wire Bead
-
DERAILLEUR, REAR
-
-
DERAILLEUR, FRONT
-
-
SHIFT LEVER
-
-
CRANKSET
Marin Forged Alloy, Alloy 32T Chainring, 104mm BCD
-
BOTTOM BRACKET
External Sealed Cartridge Bearings
-
CHAIN
KMC HL-1
-
CASSETTE
14T Single Speed Cog
-
BRAKE, FRONT
Tektro HDM275 Hydraulic Disc, 160mm Rotor
-
BRAKE, REAR
Tektro HDM275 Hydraulic Disc, 160mm Rotor
-
BRAKE LEVERS
Tektro HDM275 Hydraulic
-
HANDLEBAR
Marin Riser, 6061 Double Butted Aluminum, 31.8mm at center bulge, 38mm Rise, 750mm Width, 4º Up, 9º Back
-
STEM
Marin 3D Forged Alloy, 31.8mm clamp, 40mm extension
-
GRIPS
Marin Single Clamp Locking
-
HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
-
SEATPOST
Marin Alloy, 30.9mm
-
SADDLE
Marin DJ Saddle
-
PEDALS
Alloy Platform
-
EXTRAS
Marin Chain Tension Device
Specifications, pricing, and availability are subject to change without notice.
GEOMETRY
| SHORT | LONG | |
|---|---|---|
| STACK | 575 | 580 |
| REACH | 385 | 430 |
| HEADTUBE ANGLE | 69° | 69° |
| HEADTUBE LENGTH | 115 | 120 |
| SEATTUBE ANGLE | 69° | 69° |
| SEATTUBE LENGTH | 320 | 320 |
| TOPTUBE EFFECTIVE | 600 | 646 |
| BB HEIGHT | 317 | 317 |
| BB DROP | 22 | 22 |
| CHAINSTAY | 395 | 395 |
| WHEELBASE | 1037 | 1083 |
| STANDOVER HEIGHT | 370 | 400 |
| FORK OFFSET | 42 | 42 |
| SEATPOST DIAMETER | 30.9 | 30.9 |
| HANDLEBAR WIDTH | 750 | 750 |
| STEM LENGTH | 40 | 40 |
| CRANK LENGTH | 170 | 170 |
All lengths in millimeters
